HOLDERS6 ISCARBD DCONMSOALLBDCONWSLU .228A ASection View A-ADesignation DCONMS DCONWS LSCMS LU BD OAL LBSC-12-4-PICCO .472 .1575 .591 .5906 .6693 .858 .071SC-12-5-PICCO .472 .1969 .591 .5906 .6693 .858 .071SC-12-6-PICCO .472 .2362 .591 .5906 .6693 .858 .071SC-12-7-PICCO .472 .2756 .591 .5906 .6693 .858 .071SC-12-8-PICCO .472 .3150 .591 .5906 .6693 .858 .071SC-PICCOReduction Sleeves for Round Shank Holders for Modular Back-End Machining System
